■ RF combiner, used for combining several incoming signals together and transmit one output signal. Multi-band combiners combine different dual frequency bands onto the same feeder systems. Multi-Band Combiners are designed for cost effective antenna sharing for outdoor and indoor applications. Provides a wide range of Multi-Band Combiner products for 2G, 3G, 4G,5G and LTE systems. The Multi-Band Combiners can be customized to combine specific frequency spectrums without incurring high insertion loss allowing operators to integrate their frequencies into a common antenna system with greater ease and efficiency.
Feature
◆ More than 50~100 dB Input Isolation,
◆ High Average Power,Minimal Insertion Loss,
◆ Multiple IP Degree Conditions,
◆ Custom Designs Available,
SPECIFICATION
Part number | ZHCM-070818212305M-5F1A |
Product Type | Five-plexer |
Frequency Range(MHz) Band1 Band2 Band3 Band4 | 698-787 806-894 1850-1995 1710-1780&2110-2180 2305-2690 |
Insertion Loss (dB) | ≤0.5 |
Ripple in-band(dB) | ≤0.4 |
Isolation(dB) | ≥60 |
Return Loss(dB) | ≥20 |
PIM(dBc) +43 dBm x 2 | ≤-150 |
Impedance(Ω) | 50 |
Ingress protection | OutdoorIP67 |
Connectors | 4.3-10-F |
Power Rating(W) | 200 |
Temperature(℃) | -20 to 70 |
Application Scenarios
