Leading Power Splitter Supplier
CNCR is a global leading supplier providing telecom access network solutions. Since the company was successfully listed in 2011, CNCR has always adhered to independent research and development and technological innovation, and successfully passed the highest level CMMI5 certification in the global software field.
-
![2 Way Power Splitter]()
2 Way Power SplitterPower splitter allow you to use a common distributor system applications in the broad frequency range.read more -
![555-6000MHz 2 Way Power Splitter]()
555-6000MHz 2 Way Power SplitterPower splitter allow you to use a common distributor system applications in the broad frequency range.read more -
![180 Degree Rf Splitter]()
180 Degree Rf SplitterPower splitter is a device that divides one input signal energy into two or multiple outputs of equal or unequal energy. It can also be used as a combiner to combine multiple input signals into oneread more -
![Two Way Power Splitter]()
Two Way Power SplitterExcellent VSWR. High power rating. Low PIM. High Reliability and Maintenance free. Multiple IP Degree Conditions . RoHS Compliant. N , DIN 4.3-10 connectors. Custom Designs Available,read more -
![Three Way Power Splitter]()
Three Way Power SplitterWhen the signal is distributed for the in-house distribution, in offifice buildings or sports halls, power splitter can split up the incoming signal in two, three, four or more identical shares.read more -
![2 Way Power Divider]()
2 Way Power DividerPower splitter is a device that divides one input signal energy into two or multiple outputs of equal or unequal energy. It can also be used as a combiner to combine multiple input signals into oneread more -
![Rf Divider]()
Rf DividerPower splitter is a device that divides one input signal energy into two or multiple outputs of equal or unequal energy. It can also be used as a combiner to combine multiple input signals into oneread more -
![4 Way Power Divider]()
4 Way Power DividerPower splitter is a kind of input signal energy into two channels or multiple output equal or unequal energy device.read more -
![3 Way Rf Power Divider]()
3 Way Rf Power DividerWhen the signal is distributed for the in-house distribution, in offifice buildings or sports halls, power splitter can split up the incoming signal in two, three, four or more identical shares.read more -
![2 Way Rf Power Divider]()
2 Way Rf Power DividerPower splitter allow you to use a common distributor system applications in the broad frequency range.read more -
![500-6000MHz 2 Way Power Splitter]()
500-6000MHz 2 Way Power SplitterExcellent VSWR. High power rating. Low PIM. Multi-Band Frequency Coverage. Low Cost Design. High Reliability and Maintenance free. Multiple IP Degree Conditions . RoHS Compliant. N , DINread more -
![5G Power Splitter]()
5G Power SplitterPower splitter is a device that divides one input signal energy into two or multiple outputs of equal or unequal energy. It can also be used as a combiner to combine multiple input signals into oneread more
Power splitter allow you to use a common distributor system applications in the broad frequency range.
When the signal is distributed for the in-house distribution, in buildings or sports halls, power splitter can split up the incoming signal in two, three, four or more identical shares.
Divide one signal into multichannel ones, that ensures the system to share common signal source and BTS system.
Why Choose Us
Professional Engineer
500+ experts provides innovative solutions to ensure project quality and reliability.
Customizable R&D
Meet personalized needs, reduce costs, protect intellectual property rights, improve competitiveness, and enhance user experience.
Real-Time Support
7*24 hours global technical support service, quickly solve problems and improve user experience.
Certified Quality
CNCR products have passed various international certifications such as ISO, CE, ROHS, improve customers' market competitiveness.
Types of Power Splitter
2 Way Power Splitter
Also known as a 2-way power splitter, it takes one input signal and splits it into two output signals. It is commonly used in applications where a single input needs to be distributed to two separate devices or components.
180 Degree Rf Splitter
RF splitter is an electronic device that allows a single RF signal to be split into multiple signals and distributed to different devices.
Three Way Power Splitter
A three-way power splitter takes one input signal and splits it into three output signals. It is used when a single input needs to be distributed to three separate devices or components.
5G Power Splitter
It's essential in 5G infrastructure for tasks like distributing signals to multiple antennas or devices, or for testing and signal distribution in various applications.
4 Way Power Splitter
Also known as a 4-way power splitter, it takes one input signal and splits it into four output signals. It is used when a single input needs to be distributed to four separate devices or components.
Specification
|
Part number |
ZHSP-046003N-5F1B |
|
Number of outputs |
3 |
|
Frequency (MHz) |
400-6000 |
|
Insertion loss (dB) |
≤5.3 |
|
VSWR at input |
＜1.4 |
|
Isolation(dB) |
N/A |
|
PIM3 (dBc) * |
≤-150 @ +43dBm×2 |
|
Impedance (Ω) |
50 |
|
Average Power (W) |
200 |
|
Application |
Indoor |
|
Temperature (℃) |
-35 to +75 |
|
Connectors |
N-F |
Advantages of Power Splitter
Signal Distribution Efficiency
Allows one RF input signal to be evenly split into multiple outputs without significant signal loss.
Convenience
Power splitters provide a convenient solution to connect multiple devices to a single power source.
Low Insertion Loss
Designed to minimize the amount of signal lost while passing through the splitter.
Space-saving
Offers a space-saving solution for distributing RF signals in tight or integrated electronic systems.
Cost-effective
Instead of purchasing multiple power adapters or extension cords, a power splitter allows you to connect multiple devices using a single power source.
Surge protection
Some power splitters come with built-in surge protection, which helps to safeguard your devices against power surges and voltage spikes.
Difference between Power Splitter and Power Divider
In general, the terms “power divider” and “power splitter” are used interchangeably to describe a device that splits an input signal into two or more output signals. However, in certain contexts, there can be a slight difference in their definitions:
Power Splitter
A power splitter is also a device that divides an input signal into multiple output signals. However, unlike a power divider, a power splitter may not necessarily provide equal power levels in each output. It can divide the power unevenly based on the specific requirements of the application.
Power Divider
A power divider is a device that splits an input signal into two or more output signals with equal power levels. It is commonly used in applications where the power needs to be divided equally among multiple devices or components.
Uses of Power Splitter
Antenna Sharing: Enables multiple transmitters or receivers to share a single antenna system without interference.
Test and Measurement Systems: Splits RF signals into multiple paths for simultaneous testing or monitoring by different instruments.
Radar Systems: Distributes RF power to multiple radar modules or channels for synchronized operation.
Telecommunication Infrastructure: Used in base stations to split signals between multiple transceivers or antennas.
How to Connect an RF Power Splitter in a System
To connect an RF power splitter in a system, follow these steps. First, identify the input and output ports on the splitter. Connect the RF signal source, such as an antenna or transmitter, to the input port using a coaxial cable. Ensure proper impedance matching for optimal signal transfer.
Next, connect the output ports to the desired components in your system using additional coaxial cables. The power splitter divides the incoming signal evenly among the output ports, making it suitable for applications like signal distribution or combining signals. Maintain good cable management practices to minimize signal loss and interference.
Consider the power handling capabilities of the splitter to prevent damage. Some splitters may require external power, so ensure proper power connections if needed. Verify that the connected devices support the frequency range of your RF system. Test the system to ensure proper signal distribution and quality.
Order Process
Contact our sales team online via email at sarah.gu@cncr-it.com and provide the products and quantities you need to order and your customization requirements.
Once we receive your custom requirements, we will contact you via email to confirm your order requirements.
Once everything is confirmed, we will send you a quotation for your approval.
Once we get your approval, we will start processing your custom order.
Our technicians will control the quality during the production process.
According to the delivery time, we will arrange shipment after receiving the remaining payment.
Payment & Delivery
| Accepted Delivery Terms: | FOB, CIF, FCA, EXW； |
|
Accepted Payment Currency: |
USD; |
|
Port: |
Xiamen ,China |
|
Accepted Payment Type: |
T/T,L/C,Credit Card,PayPal,Western Union |
Video
Patents & Certificates
In pursuing innovation of cutting-edge technologies, CNCR has been publishing patents every year.
Factory Environment
FAQ
We're well-known as one of the leading power splitter manufacturers in China since 1999, specialized in providing high quality customized products. Welcome to buy cheap power splitter for sale here from our factory. For price consultation, contact us.
