■ Directional couplers are used as a measuring device to monitor the coupling out signals. The coupling value is from 3 dB to 60 dB or more.
■ Applied to the network sites demanding for corresponding signal strength and also as a signal power monitoring device.
Feature
◆ Low Variation of Coupling Attenuation,
◆ High directivity/ Isolation, Low VSWR/Insertion Loss,
◆ Broad Band Operating Frequency Range,
◆ High Average Power Rating,
◆ Excellent PIM,
◆ Multiple IP Degree Conditions
◆ Low Cost Design, Design to Cost,
◆ N , DIN 4.3-10 Connectors,
◆ Custom Designs Available,
SPECIFICATION
Part number | ZHCP-063803N-5F1A |
Coupling(dB) | 3 |
Frequency (MHz) | 698-3800 |
Insertion Loss(dB) | ≤0.8 |
Ripple in band(dB) | ≤±0.8 |
Directivity(dB) | ≥20 |
VSWR | ≤1.2 |
Impedance(Ω) | 50 |
PIM3(dBc)* | ≤-150@+43dBm×2 |
Connectors | N-F |
Power rating(W) | 200 |
Temperature(℃) | -30~+70 |
Application | Outdoor IP65 |
Application Scenarios
