■ Hybrid Coupler allows addition of two or more signals, without interaction regardless of how close the frequencies of the signals may be. So,it is mainly used to combination and division of the same frequency signal.
■ An important advantage is that they have many outputs same as inputs. So, if a system needs multiple outputs, the hybrid matrix could be considered as a ‘lossless’ combiner.
Feature
◆ High Isolation,
◆ Multi-Band Frequency Coverage,
◆ High Average Power Rating,
◆ Excellent PIM performance,
◆ Multiple IP Degree Conditions,
Specification
Part number | ZHHY-070903D-5U1A | ZHHY-182103D-5U1A | ZHHY-232703D-5U1A | ||
Quantity of in&out port | 2IN2OUT | 2IN2OUT | 2IN2OUT | ||
Frequency Range(MHz) | 700-960 | 1805-2170 | 2300-2700 | ||
Coupling(dB) | 3.01±0.25 | 3.01±0.25 | 3.01±0.25 | ||
Isolation(dB) | ≥25 | ≥25 | ≥25 | ||
VSWR | ＜1.2 | ＜1.2 | ＜1.2 | ||
PIM3(dBc) @+43dBm×2* | ＜-150 | ＜-150 | ＜-150 | ||
Impedance(Ω) | 50 | 50 | 50 | ||
Connectors | DIN-F | DIN-F | DIN-F | ||
Power Rating(W) | 1000 | 1000 | 1000 | ||
Temperature(℃) | -20~+50 | -20~+50 | -20~+50 | ||
Humidity | 5% to 95% | 5% to 95% | 5% to 95% | ||
Sealing | Indoor | Indoor | Indoor | ||
