Description

Technical Parameters

■ Hybrid Coupler allows addition of two or more signals, without interaction regardless of how close the frequencies of the signals may be. So,it is mainly used to combination and division of the same frequency signal.

■ An important advantage is that they have many outputs same as inputs. So, if a system needs multiple outputs, the hybrid matrix could be considered as a ‘lossless’ combiner.

Feature

◆ Low Cost Design, Design to Cost,

◆ RoHS Compliant,

◆ Custom Designs Available,

SPECIFICATION

Part number	ZHCU-082733N-5U1A
Quantity of in&out port	3IN3OUT
Frequency Range(MHz)	800-2700
Coupling(dB)	5±1.3
Isolation(dB)	≥25
VSWR	<1.2
PIM3(dBc)@+43dBm×2	<-150
Impedance(Ω)	50
Connectors	N-F, DIN-F
Power Rating(W)	200
Temperature(℃)	-20~+50
Humidity	5% to 95%
Sealing	Indoor

Our advantage

We have our own R&D center, workshop and the rich experience technical support team. We specialize in custom-designed products and high-tech requirements product with the competitive price, good quality and service after-sales

QUALITY ASSURANCE

Professional test equipment,

Professional production line,

Professional quality management system

Professional engineers guide installation

Provide one year warranty

SERIVICE

Leading RF technology and product developer

Leading provider of wireless network coverage products and solutions

In addition to products, we can also help customers design IBS solutions.

Application Scenarios
