Description
Technical Parameters
Type No. | ZHDX-080903NS-5U1B | |
Device Type | 900MHz Diplexer | |
Frequency Band(MHz) | RX: 880~915 | TX:925~960 |
Insertion Loss(dB) | <1.2 | <1.0 |
Isolation (dB) | >90 | >90 |
Return Loss(dB) | >20 | |
Intermodulation Products(dBc) | <-150(3rd order; with 2 x 20 W) | |
Input Average Power ,Continuous（W） | 50 | 200 |
Temperature Range(℃) | -40~+55 | |
Impedance(Ω) | 50 | |
Connectors | ANT:N-Female other:SMA-F | |
Application | Indoor | |
Color | Silver | |
