SPECIFICATION
Type No. | ZHDX-070803NS-6U1A | |
Device Type | DD800 Diplexer | |
Frequency Band(MHz) | RX: 832-862 | TX:791-821 |
Insertion Loss(dB) | <1.0 | <1.0 |
Isolation (dB) | >80 | >80 |
Return Loss(dB) | >20 | |
Intermodulation Products(dBc) | <-150(3rd order; with 2 x 20 W) | |
Input Average Power ,Continuous（W） | 50 | 200 |
Temperature Range(℃) | -40~+55 | |
Impedance(Ω) | 50 | |
Connectors | ANT:N-Female other:SMA-F | |
Application | Indoor | |
Color | Silver | |
Considering the majority of voice and data traffic originates from within buildings, it is unsurprising that indoor wireless coverage and capacity issues are getting a lot of attention. Traffic has increased drastically because of the smartphone applications and online games. Strong indoor coverage is therefore crucial to effectively utilize network capacity. Hence, operators have been placing a lot of emphasis on indoor coverage enhancement investment.
CNCR’s indoor wireless enhancement solution supports deployments under different scenarios. The effective design of end-to-end solutions can meet different requirements from operators, for instance, combining repeaters and small cells in the deployment can provide both coverage and capacity to the indoor users at office buildings. Network monitoring system is available to provide full remote control of the system which enables higher operation efficiency.
CNCR’s Indoor coverage enhancement solutions include Comflex DAS, mBDA, RX series high power repeater, small cell solution.
