Specification
Part number | ZHDX-343503D-6U1A |
Pass band(MHz) RX Band TX Band | 3440-3460 3520-3590 |
Insertion Loss (dB) | ≤1.2 |
Ripple in-band (dB) | ≤0.8 |
Isolation (dB) | ≥90 |
Average Power (W) | 200 |
Return Loss (dB) | ≥20 |
Connectors | DIN-F |
PIM3(dBc)@ 43dBm×2 | ≤-165 |
Impedance (Ω) | 50 |
Temperature (℃) | -40 to +60 |
Application | indoor |
4G LTE networks are keys to supporting the rapid rate and higher volumes of mobile data traffic growth driven by increased smartphones and connected devices. As a result, LTE upgrade deployment has been the top priority in operator action list in order to meet the demands.
Indoor LTE deployment to achieve good MIMO performance requires high SINR and good balance between the paths. Furthermore, indoor passive inter-modulation (PIM) interference issues are exacerbated in multi-carrier and multi-system circumstances, which may result in poor user experience.
As the leading wireless solution provider, CNCR provides end-to-end solution which cover system design, implementation as well as system performance verification and optimization. CNCR’s rich global experiences in Asia, Europe, Middle East and other regions enables fast network upgrade with reliable performance.
CNCR’s LTE upgrade solutions include customized combiner and POI solution, MIMO antenna and DAS.
