■ Filter is designed to suppress harmonics and out of band noise and interference ,to improve signal quality.
■ This helps minimizing the inevitable loss of useful power, and results in high stop band attenuation and steep filter edges.
Feature
◆ 3G/4G/5G LTE Coverage
♦ Low PIM & low vser
♦ Widely used for in-building Soloution
♦ IP60 applicationn
♦ High reliability
♦ Simple installation
Specification
Specification | |
ZHFT-005602S-2U1A | |
Power Rating(W) | 40 |
IM3(dBc) | ≤-100@+40dBmX2 |
In/Out Impedance(Ω) | 50 |
Temp.Range(℃) | SMA-F |
Rejection band(MHz) | 690 ~ 1400 |
Attenuation Absolute Value(dB) | ≥80 |
Pass Band | 9 kHz ~ 560 MHz |
IL at BW (dB) | ≤1.0 |
Ripple in-band (dB) | ＜1.0 (DC~560MHz passband) |
Return loss at BW (dB) | ≥14 |
Dimensions (mm) | 159.4×70×20 |
Weight(kg) | 0.36 |
Application Scenarios
Company Profile
FAQ
Shipping Method:
For small qtty will be shipped by courier door to door e.g: DHL, UPS, EMS, FEDEX IE, FEDEX IP, TNT ( shipping days 3-4 days)
For bigger qtty will be shipped by sea shipment to your pointed nearest seaport ( shipping days 1 month)
Why choose us?
1. Manufacturer Place your order directly to the factory, no intermediate cost, more fast delivery ,better service and economical cost.
2. Strict QC inspection Good quality is top important during cooperation. We will make QC inspection strictly before ship out to make sure every piece stayed in a good condition. If any problems made by us after you received cases then we will full responsible to compensate you.
3. Stable Supply As a manufacturer with strong ability for phone cases production, we have enough stock to meet your needs.
4. Fast delivery Enough stock in the warehouse, normal order can be delivery in 1-2 days.
5. Professional sale team with the best after-service professional and experienced sales team will provide you excellent service.
How to place your order:
1. Send us your order list (models/quantities/specification)
2. we will send you PROFORMA INVOICE (PI) with shipping cost and Payment information for your confirmation.
3. You arrange payment after you confirmed proforma invoice, we will arrange production after received your payment notice.
Specific delivery date depends on your specific needs, normally delivery in 1-3 days.
4.We will arrange delivery after your payment arrived and goods ready,and at the same time we will tell you goods tracking number so that you could know your goods condition by this number from courier site.
5.You will receive your order in about 3-5 days after goods ship out.
