Attenuator has the following basic purposes:
1. Control power levels: in the microwave superheterodyne receiver output power of the vibration control, the best noise figure and conversion loss, the best reception. In the microwave receiver, automatic gain control, improved dynamic range.
2. Decoupling components: as the oscillator and the load to the coupling between the components.
3. The relative standard: as a comparison of the relative standard power level.
4. For radar jamming transition in the attenuator: a mutation of attenuation can be variable attenuator, usually without introducing attenuation, encountered outside interference, the sudden increase attenuation.
Feature
◆ Power Rating 5W to 500W, 1 dB to 60 dB,
◆ High Reliability,
◆ Low VSWR,
◆ Low PIM Performance,
◆ Multiple IP Degree Conditions,
Specification
|
Part number |
ZHAT-030520DN200-6U1A |
|
Frequency Range(MHz) |
340-390 |
|
Average Power(W) |
200 |
|
VSWR |
≤1.2 |
|
Attenuating(dB) |
±0.5 |
|
PIM3(dBc) |
<-160@+43dBm×2 |
|
Impedance (Ω) |
50 |
|
Connectors |
DIN/N |
|
Temperature(℃) |
-40~+65 |
|
Application |
indoor |
