RF dummy loads also called RF termination loads, or RF terminations, it is mainly used to absorb the power of the RF or microwave system. Termination Load / dummy load is a resistive component and indispensable components in many RF, microwave systems where signal reflection from unused ports can potentially damage the device or reduce the signal. By using a termination load on an unused port, the incident energy will be absorbed with minimal reflection, it acts as a protector. The termination load is commonly used to terminate devices, such as couplers, circulators and switches. They are wide used in military and civilian communication markets, such as BS& DAS, broadcast television, mobile communication, aerospace, radar, medical equipment etc., they are also widely used in measurement systems to ensure accurate results.
Feature
◆ Finned termination
◆ Designed for wireless applications
◆ Low VSWR
SPECIFICATION
Part number | ZHLD-0030100M-5U1A |
Frequency Range (MHz) | 0-3000 |
Average Power(W) | 100 |
VSWR | ≤1.2 |
PIM3(dBc)@ +43dBm×2* | <-150 |
Impedance(Ω) | 50 |
Connector | 4.3-10M |
Temperature(℃) | -40~+65 |
Application | indoor |
Application Scenarios
