■ Filter is designed to suppress harmonics and out of band noise and interference ,to improve signal quality.
■ This helps minimizing the inevitable loss of useful power, and results in high stop band attenuation and steep filter edges.
Feature
◆ Low Insertion Loss ,High Power Rating,
◆ High Stop Band Attenuation and Steep Filter Edges ,
◆ Excellent Passive Intermodulation Properties,
◆ High “Q” Design , Narrow Bandwidth,
◆ High Notch Attenuation Design,
◆ RoHS Compliant,
◆ N , DIN 4.3-10 Connectors,
Specification
Part Number | ZHFT-445002S-2U1A | ZHFT-515302S-2U1A |
Frequency Range (MHz) | DC-4100& 5200-6000 | DC-4500 &6000-7000 |
IL at BW (dB) | <1.8 | <1.8 |
Rejection(dB) @MHz | >60@4400-5000 | >60@5150-5350 |
Return loss at BW (dB) | >15 | >15 |
In/Out Impedance (Ω) | 50 | 50 |
IM3 (dBc) @+43dBm×2 | N/A | N/A |
Connectors | SMA-F | SMA-F |
Input Power (W) | 50 | 50 |
Temp.Range (℃) | -20~+55 | -20~+55 |
Application | Indoor | Indoor |
Application Scenarios
