RF Filters Cavity Filter are components used to resolve radiated interference. They can attenuate high-frequency interference signals to a large extent and only allow frequencies that are being transmitted or received to pass. Includes low-pass rf filters, high-pass rf filters, band-pass rf filters, and band-stop rf filters.
Feature
◆ High Quality,easy installation
◆ Durable&Long Service Life
◆ A variety of components can be chosen
◆ All data sheets can be changed as customer's requirments
Specification
Product Model | ZHFT-601302N-2U1A |
Pass band（MHz） | 6000 ~ 13000 |
Return Loss（dB） | >10 |
Insertion Loss（dB） | ≤ 1 |
Rippler（dB） | ≤0.5（any 20 MHz） |
| Rejection Band | DC ~ 2700 MHz |
rejection（dB） | ≥ 70 |
| Average Power（W） | 20 |
Peak Power（W） | 150 |
Impedance（Ω） | 50 |
Temp（℃） | +18 ~ +40 |
Connector | N-F |
Size（mm） | 350.1×32×21.4 |
Weight(kg) | 1.3 |
Application Scenarios
