■ Combiners are used to unite two or more different frequencies sharing the common antenna feed cable or one antenna by several transmitters or receivers.
■ Combiner collects all the signals from different systems to an antenna port and allows that different systems share one set of antenna and cable equipment
Feature
●Wide Frequency Range
●Excellent Coupling Flatness
●High Directivity / Isolation
●Cavity structure, High power handing
●Low Insertion Loss, Low VSWR, Low PIM(IM3)
SPECIFICATION
Part number | ZHCM-07171903D-5F1B |
Product Type | Triplexer |
Frequency Range(MHz) CDMA-GSM DCS 3G/UMTS/WCDMA | 690-960 1710-1880 1920-2170 |
Band Width(MHz) | 270/170/250 |
Insertion Loss (dB) | ≤0.3 |
Ripple in-band(dB) | ≤0.25 |
Isolation(dB) | ≥50 |
Return Loss(dB) | ≥20 |
PIM(dBc) +43 dBm x 2 | ≤-150 |
Impedance(Ω) | 50 |
Ingress protection | OutdoorIP67 |
Connectors | DIN-F |
Power Rating(W) | 200 |
Temperature(℃) | -20 ~+70 |
OUR ADVANTAGE
We have our own R&D center, workshop and the rich experience technical support team. We specialize in custom-designed products and high-tech requirements product with the competitive price, good quality and service after-sales
Leading RF technology and product developer
Leading provider of wireless network coverage products and solutions
In addition to products, we can also help customers design IBS solutions.
