Product Overview
This combiner unite 4 different frequencies (825-835, 870-880,890-960&1700-2700)sharing the common antenna feed cable or one antenna by several transmitters or receivers.
Product Feature
Integrates 4 way Wireless Bands,
More than 90 dB Input Isolation,
High Average Power,Minimal Insertion Loss,
Superior Intermodulation Properties Prevent,
Multiple IP Degree Conditions,
Product Specification
Part number | ZHCM-08080803D-6U1A |
Product Type | Triplexer |
Frequency Range(MHz) Band1 Band2 Band3 Band4 | 825-835 870-880 890-960&1700-2700 |
Insertion Loss (dB) | ≤0.8 |
Ripple in-band(dB) | ≤0.6 |
Isolation(dB) | ≥90 |
Return Loss(dB) | ≥20 |
PIM(dBc) +43 dBm x 2 | ≤-160 |
Impedance(Ω) | 50 |
Ingress protection | Indoor |
Connectors | DIN-F |
Power Rating(W) | 200 |
Temperature(℃) | -20 to 70 |
Application Scenarios
Company Profile
FAQ
Q: Are you trading company or manufacturer?
A: We are manufacturer, having our own factories.
Q: Do you provide samples ? is it free or extra?
A: Sorry, we can pnot rovide free samples.
Q: How long is your delivery time?
A: Generally, if the goods are in stock, shipment can be arranged within 3 working days;
If the goods need to be mass produced, delivery time may be around 7-10 working days.
Your inquiry will be answered within 24 hours.
Wishing to be your long-term partner.
Please feel free to contact us we will do our best for you.
