Product overview
■ It unite 5 way different frequencies sharing the common antenna feed cable or one antenna by several transmitters or receivers.
■ Collects all the signals from different systems to an antenna port and allows that different systems share one set of antenna and cable equipment
Feature
Integrates 5 way Wireless Bands,
More than 50~100 dB Input Isolation,
High Average Power,Minimal Insertion Loss,
Superior Intermodulation Properties Prevent,
Brackets for Mast and Wall mounting,
Multiple IP Degree Conditions,
SPECIFICATION
Part number | ZHCM-070818212305M-5F1A |
Product Type | Five-plexer |
Frequency Range(MHz) Band1 Band2 Band3 Band4 | 698-787 806-894 1850-1995 1710-1780&2110-2180 2305-2690 |
Insertion Loss (dB) | ≤0.5 |
Ripple in-band(dB) | ≤0.4 |
Isolation(dB) | ≥60 |
Return Loss(dB) | ≥20 |
PIM(dBc) +43 dBm x 2 | ≤-150 |
Impedance(Ω) | 50 |
Ingress protection | OutdoorIP67 |
Connectors | 4.3-10-F |
Power Rating(W) | 200 |
Temperature(℃) | -20 to 70 |
Application Scenarios
Company Profile
FAQ
Q: I don't see my designed dimensions/packaging/delivery etc. Can you make a special order for us?
A: Sure. We're truly customized. You're free to tell us whatever you want.
Q: Do you deal with urgent orders?
A: Sure. Please contact ASAP for details.
Q: I bought from you once. Can I have a special offer this time?
A: Contact for details. We do value our customers; we can and will offer you good price. :)
Q: How the product pricing and how to consult prices?
A:We pricing the products according to the customers' order quantity. And you can inquiry by TM,skype or send e-mail to us.
Q :How many days will samples be finished? And how about the mass production?
A: Sample leadtime: usually need 7-10days. Mass production leadtime usually need 30 days
If you are the urgent order,we can delivery about 20 days.The actual situation is different for different products
Q:If the products have some quality problem,how will you deal with it?
A: Each step of production and finished products will be inspected by QC department before shipping.If the quality problem of products caused by us, we will provide a replacement service.
Q:Could you provide samples for test?
A: Yes, we provide our customers with samples , but it is not free
Q:How to make payment?
A:T/T,L/C, we also accept most other convenient methods of payment.
